Application:
The frame is for the production of 20-100g/squ.m water soluble non woven fabrics which used as linings of garments and embroideries.The raw materials are treated by the process of opening and blending, chute feeding,, carding cross lapping, air laid, saturation imparting, horizontal heating chamber, round-mesh vertical heating chamber, accumulator, calendering and fabric Rewinding.

Main Specification:

• Raw material: Vinylon (PVA) 1.5D-4D, 38-51mm
• Final width:2000mm or as per customer requirement
• Speed of the frame:3－25m／min
• Specification of the finished product:Sticky linings of 20-100g/squ.m
• heated by：heat-conducted oil、steam and natural gas
• General power：150KW



•
