1. Purpose:
This type of machine is mainly used to loosen hard and soft fibre waste, make waste cotton, linen, rough yarns and flax into fibre.
2. Characteristics:
The framework of the machine is totally made of steel, and has a nice out-looking. The machine is combined of separated Cabinets in convenience of choices from users. For example, you can use only one Cylinder to loosen rough yarns; to loosen waste cottons,
you can use one Cylinder with two Wire cabinets; to loosen hard fibre waste, you can use one Cylinder with three Wire cabinets, etc.. This machine is also compact, safe, simply composed, easily operated and performs well in removing dust and impurities.
3. Main technological parameters:
Diameter of Cylinder hammer ——————– 400mm
Speed of Cylinder hammer ———————- 1127rpm
Diameter of Balance roller ————————– 76mm
Diameter of Dust cage —————————— 574mm
Diameter of Pressure roller ———————— 203mm
Diameter of Wire roller —————————– 250mm
Wire ————————— 1.09 * 75°* teeth/5.64mm
Speed of Wire roller ——————————- 2160rpm
Diameter of Feeding roller ————————– 57mm
Capacity of fan ———————————— 1500m³/h
Power: 5.83kw for Cylinder, 3.85kw for Wire cabinet
Power in total: 5.83kw + N*3.85kw, N = number of Wire cabinets
Framework Size (L*W*H): Cylinder— 2100*1482*1380mm
Wire cabinet — 1200*1482*1380mm
Length in total: 2100+N*1200mm, N = number of Wire cabinets
Weight: Cylinder —- 900kgs, Wire cabinet —- 450kgs
Weight in total: 900+N*450kgs, N = number of Wire cabinets
